Kauffmann-Bremin DT-2 Night Vision  Goggles

The Kauffmann-Bremin DT-2 is the newest housing from the original designer of the DTNVG, serving as its spiritual successor and offering a lightweight, rugged, and highly serviceable platform. Built from high-density injection molded polymers in Europe, the DT-2 is a no-frills, straightforward, and ergonomic articulating binocular designed for both professional end-users and dedicated hobbyists.

Borrowing design cues from the wildly popular DTNVG, the DT-2 improves on serviceability and user experience, offering a simple yet highly effective housing that is easy to maintain, budget-friendly, and EU-made—without sacrificing quality.

Key Features

• Individual Pod Shut-off when rolled out of view

• Device Auto-Off when stowed vertically

• Simple Two-Position Paddle Switch for intuitive controls (glove-friendly)

• Accepts 1x CR123A Battery with 20–25+ hours runtime

• Low Battery Indicator inside eyepiece (~30 minutes warning)

• Friction-Lock IPD System ensures pods return to the same position every time (Note: U.S. shipments do not include this feature)

• Ultra-Low Stowage Angle with angled arm design

• Exceeds MIL-STD-810G/H & NATO 1.5m Drop Test Standards

• Dust-proof & Waterproof to 1.5m / Exceeds IP68 immersion ratings

• Built-in Aluminium Dovetail Mount

• No Onboard IR Illuminator for maximum durability and simplicity

Technical Specifications

• Material: High Density Injection Molded Polymer

• Tube Type: 2-Contact MX-10160 IIT

• Weight: 557g (with Noctis optics & battery) | 490g (with RPO NVD-N optics)

• Battery Type: 1x CR123A

• Runtime: ~25 hours @ 18°C (65°F)

• Power System: Onboard only (no remote power)

• Field of View: 40° (standard) / 50° (Boomslang Wide FOV)

• Diopter Adjustment: +2 to -6

• Impact Rating: MIL-STD-810H

• Water Immersion: Rated up to 18m for 2 hours

• Operating Temp: -30°C to +50°C

• Storage Temp: -50°C to +70°C

• Auto Functions: Auto-off on stow, pod shut-off on roll-out

What’s Included

• KB DT-2 Complete NV Binocular Housing

• NVG Lens Storage Caps

• Operator’s Manual LLC Pro Case

• Hoffman test report & tube spec sheet

• 10-Year Operator’s Manual LLC Warranty

• User Manual

Built & Tested by Operator’s Manual LLC

All night vision systems are custom-built to your specifications in our ISO5-certified positive pressure clean room. Each unit undergoes assembly, calibration, and testing with:

• Hoffman ANV-126A & HVS-126 digital night vision test equipment

• Vacuum Argon purge process using digital purge machinery

Please allow up to one week for assembly, calibration, and final testing before shipment.

With the DT-2, Operator’s Manual LLC delivers a housing that strikes the perfect balance between simplicity, ruggedness, serviceability, and performance—built for those who demand reliability in the harshest environments.
